1. Diesel engine: provides prime mover, including operating system, charging system, oil lubrication system, fuel system, cooling system, and intake and exhaust system.
2. Generator: Typically a three-phase AC brushless synchronous generator that converts mechanical energy into electrical energy.
3. Control panel: realizes the conversion between mains power and oil engine power generation, controls the speed and voltage of the generator set.
4. Coupling: Connect the power output shaft of the diesel engine to the shaft of the generator.
5. Radiators: Used for cooling the system and maintaining the normal operating temperature of the engine.
6. Fuel tank: stores fuel and supplies the fuel required for diesel engine combustion.
7. Muffler: Installed on the exhaust pipe to reduce noise.
8. Bellows: installed between the exhaust pipe and the machine body, providing cushioning and shock absorption.
9. Public base: Fixed unit, some bases are also processed with built-in fuel tanks.
10. Cover: Protect the unit and prevent external factors from affecting it.
11. Flywheel: Installed on the main shaft to ensure the balance of the unit's operation.
These components work in coordination with each other to ensure the normal operation of Weichai generator sets.
